UNI-T MSO2202 200MHz 2+16Ch MSO Digital Oscilloscope

Discover Precision Measurement with the UNI-T MSO2202 Mixed Signal Oscilloscope (MSO) UNI-T MSO2202 Oscilloscope LA Logic Analyzer<p>The UNI-T MSO2202 Mixed Signal Oscilloscope (MSO) is your gateway to multifunctional, high-performance measurement solutions, built on UNI-T's cutting-edge Ultra Phosphor technology. This versatile instrument seamlessly combines user-friendliness, exceptional technical prowess, and a wealth of features, accelerating your measurement tasks. Tailored for diverse applications in communication, semiconductor, computer, instrumentation, industrial electronics, consumer electronics, automotive electronics, on-site maintenance, and R&amp;D/education, it empowers you to capture abnormal events like video signals, jitter, noise, and low waveforms with precision. Equipped with two analog channels and 16 digital channels (including the UT-M15 Logic probe), the UNI-T MSO2202 Mixed Signal Oscilloscope ensures accurate measurements across various domains.</p>UNI-T MSO2202 Mixed Signal Oscilloscope Key Specifications:<ul> <li><strong>BANDWIDTH:</strong> 200MHz</li> <li><strong>ANALOG CHANNELS:</strong> 2</li> <li><strong>DIGITAL CHANNELS:</strong> 16 (UT-M15 Logic probe included)</li> <li><strong>REAL-TIME SAMPLE RATE:</strong> 2GSa/s</li> <li><strong>MAX. MEMORY DEPTH:</strong> 56Mpts</li> UNI-T MSO2202 Oscilloscope 4M pts enhanced FFT <li><strong>WAVEFORM CAPTURE RATE:</strong> 1,000,000wfms/s</li> <li><strong>DISPLAY:</strong> 8in Multi-point Capacitive Touchscreen</li></ul><p><strong>Impressive Bandwidth:</strong> Boasting a 200MHz bandwidth, the UNI-T MSO2202 Mixed Signal Oscilloscope is primed for various applications. When considering an oscilloscope, remember the "Rule of Five" – opt for a bandwidth at least five times greater than the fastest signal you intend to measure. For the MSO2202, we recommend applications at 40MHz and below.</p><p><strong>Enhanced FFT Analysis:</strong> With support for full screen/split screen/waterfall chart and multiple detections, the UNI-T MSO2202 Mixed Signal Oscilloscope provides rich frequency domain measurement information. Utilize FFT (Fast Fourier Transform) mathematical operations to seamlessly convert time-domain signals (YT) into frequency-domain signals. Explore harmonic content, measure distortion, delve into noise features, and analyze vibration.</p><p><strong>Advanced Trigger Functions:</strong> Harness an array of advanced trigger options, including edge, pulse width, video, and more, with the UNI-T MSO2202 Mixed Signal Oscilloscope to capture and display your signals of interest accurately and swiftly.</p> UNI-T MSO2202 Oscilloscope Logic Analysis Probe<p><strong>Robust Logic Analysis:</strong> The UNI-T MSO2202 Mixed Signal Oscilloscope excels in parallel bus analysis, protocol decoding, and precise timing measurements. Features such as Rank Selection, Data Bus Setting, and Event Lists enhance your analytical capabilities.</p><p><strong>Full Memory Hardware Decoding:</strong> Experience rapid decoding thanks to full-memory hardware decoding and deep storage of 56Mpts. This enables the UNI-T MSO2202 Mixed Signal Oscilloscope to offer real-time decoding, significantly boosting your diagnostic efficiency.</p><p><strong>Generous Memory Depth:</strong> The UNI-T MSO2202 Mixed Signal Oscilloscope maintains a high sampling rate across a wider time base range, enhancing the capture rate of abnormal waveforms.</p><p><strong>User-Friendly Interface:</strong> With our original Multi-Scopes technology, the UNI-T MSO2202 Mixed Signal Oscilloscope’s waveform display is more intuitive, making it easier for users to explore and analyze waveform details. Each channel can be customized with different frequency, amplitude, and waveform settings.</p><p><strong>Vivid Grayscale Display:</strong> Leveraging Ultra Phosphor display technology, use the UNI-T MSO2202 ensures long-term observation of waveform details and occasional abnormalities with ea</p>
